NASA Says Orion’s Artemis II Heat Shield Performed as Expected

Orion’s heat shield performed as expected when it brought the four Artemis II astronauts home from around the Moon, with about a tenth of the char loss seen on the uncrewed Artemis I flight, NASA said on 15 October 2026 after a full post-flight review.

Engineers counted nine spots of char loss of varying sizes on the Artemis II heat shield, compared with 103 on Artemis I. NASA credits a change to the reentry path that cut the time the shield spent in the temperature range that caused the earlier damage.

What the heat shield does

The heat shield is the thick dish on the base of Orion’s crew module. It is made of 186 unique blocks of an ablative material called Avcoat, whose outer layers char and burn away in a controlled way during reentry, carrying heat away from the cabin. The sloped sides of the module, the backshell, are covered with about 1,300 ceramic tiles.

Artemis II was the first time astronauts flew aboard Orion, so the shield had to show it could protect a crew on a return from lunar distance.

The numbers NASA published

  • Orion reached a maximum velocity of 39 times the speed of sound.
  • External temperatures at the heat shield peaked above 4,000°F (about 2,200°C).
  • Cabin temperature stayed in the mid-70s°F (about 24°C) during the return.
  • The spacecraft entered the atmosphere within 192 feet of its targeted entry interface.
  • It splashed down 0.59 miles from the predicted site off San Diego on 10 April 2026.

NASA said Orion’s aerodynamic and aerothermal performance, including the heat shield and backshell, matched engineering predictions from pre-flight analysis and ground testing. The seams between Avcoat blocks and the material around the compression-pad separation bolts performed consistently across both flights. The backshell tiles and the seals around windows, vents, thrusters and the side hatch showed no signs of overheating.

What went wrong on Artemis I

NASA identified the cause of the Artemis I damage in December 2024. On that flight, Orion used a “skip” entry, dipping into the upper atmosphere, lifting back out and then re-entering. Between the dips, heating rates fell and heat built up inside the Avcoat. Gases that form as part of normal ablation could not vent because the material was not permeable enough, so pressure built up, the Avcoat cracked and pieces of the charred layer broke away.

Ground tests before Artemis I had used much higher heating rates, at which the char became permeable and vented as designed, so the problem did not show up. The investigation removed about 200 Avcoat samples, ran 121 tests across eight thermal test campaigns and was checked by an independent review team. NASA said that flight data showed a crew would have been safe on Artemis I, with cabin temperatures holding in the mid-70s°F.

For Artemis II, NASA kept the existing heat shield and changed the operation instead, shortening the maximum distance Orion could fly between entering the atmosphere and splashdown.

A trajectory fix worked; the material fix flies on Artemis III

The Artemis II result shows that the trajectory workaround did what NASA said it would. It does not mean the underlying material problem has gone away. The Artemis II shield was built before the cause was known, using Avcoat with the same permeability limits. Engineers protected it by limiting how long it spent in the risky temperature band, not by changing what it was made of. Nine char-loss spots is far better than 103, but it is not zero, and NASA has not yet published the size of each spot.

That matters because a shorter downrange distance narrows the options for where Orion can come down. That is acceptable on a planned return to a known recovery zone. It leaves less flexibility if a return does not go to plan. So the lasting fix is the one NASA described after Artemis I: a heat shield for Artemis III built for more uniform Avcoat and consistent permeability. Technicians attached that shield to the Artemis III crew module at Kennedy in early July, and the crew and service modules were joined at the end of July and powered up for the first time.

The data still to come will show how much the new material buys. Laser scans of the Artemis II shield are being compared with pre-flight measurements to measure how much material burned away, and sample extraction and X-ray scans continue at Marshall Space Flight Center. Those results will show how much margin the shield had left, which is the number that matters for flights with longer or less forgiving returns.

The careful approach is the encouraging part. NASA flew an uncrewed test, found an unexpected problem and traced its cause in the lab before putting a crew aboard, rather than flying with an unexplained risk.

What comes next

NASA said it is preparing Orion for Artemis III next year, a mission in low Earth orbit to practise rendezvous with human lander test articles from SpaceX and Blue Origin ahead of a crewed landing on Artemis IV in 2028. The named Artemis III crew includes NASA astronauts Randy Bresnik, Frank Rubio and Andre Douglas, and ESA astronaut Luca Parmitano.

On 23 October, NASA said Orion will now dock with SpaceX’s Starship lander in Earth orbit before heading to the Moon, while Blue Origin’s lander will meet it in lunar orbit. SpaceX has been preparing Starship hardware, including a 33-engine static fire for Flight 15, and Blue Origin plans more Florida launch pads to raise its New Glenn flight rate.

Sources

  1. NASA, “Rigorous Analysis Confirms NASA’s Artemis II Heat Shield Performance”, 15 October 2026
  2. NASA, “NASA Identifies Cause of Artemis I Orion Heat Shield Char Loss”, 5 December 2024
